UL Style 1571-26AWG

DATASHEET

UL Style 1571, 26 AWG



PVC Insulated Wire (Poly Vinyl Chloride)

0.004” nominal wall thickness

Max.Temperature 80oC     Max. Voltage  30 Volts

Very Thin Wall, Small Diameter Wire, for use as internal wiring of Class 2 circuits in electronic equipment.



Download our data sheet



RDS Item Number

Gauge

Stranding

(Tinned Copper)

Insulation O.D.

Nominal Wall

DC Resistance

@ 20oC

UL 1571

(AWG)



(Nominal)



Ohms/1000ft

1571-26-07 -*

26

7/34

.027”

.004”

40.5













1571-26-07 -0

Black









1571-26-07 -1

Brown









1571-26-07 -2

Red









1571-26-07 -3

Orange









1571-26-07 -4

Yellow









1571-26-07 -5

Green









1571-26-07 -6

Blue









1571-26-07 -7

Violet









1571-26-07 -8

Grey









1571-26-07 -9

White











Black and White are standard stocking items.

Other colors on special order.

Also available with heavier insulation wall thickness on special order.

For more information, contact us today!
