UL Style 1429

          UL Style 1429

Appliance Wiring Material (AWM)

Irradiated (Cross Linked) PVC (Poly Vinyl Chloride Insulated)

0.010" Wall Thickness

UL 1429 -   80oC  150 Volts

Also available UL 1534- 80oC unspecified voltage

Download our Data Sheet



     Wire Type

Dimensional Data



RDS Number

Gauge

Stranding

Insulation O.D.

Nominal Weight



UL 1429

(AWG)

STANDARD

(Nominal)

(lbs./1000’)







STRANDING







1429-30-7 -*

30

7/38

.033

0.79



1429-28-7 -*

28

7/36

.036

1.09



1429-26-7 -*

26

7/34

.040

1.44



1429-26-19 -*

26

19/38

.040

1.58



1429-24-7 -*

24

7/32

.045

2.08



1429-24-19 -*

24

19/36

.045

2.14



1429-22-7 -*

22

7/30

.051

2.93



1429-22-19 -*

22

19/34

.052

3.17



1429-20-10-*

20

10/30

.058

4.21



1429-20-19 -*

20

19/32

.060

4.81



1429-18-19-*

18

19/30

.070

7.06



1429-16-19-*

16

19/29

.078

 9.50



1534-14-19-*

14

19/27

.096

13.82

 *  =  Colors  0 = Black, 1 = Brown, 2 = Red, 3 = Orange, 4 = Yellow, 5 = Green, 6 = Blue, 7 = Violet, 8 = Grey, 9 = White

14 AWG available only in UL 1534
