UL Style 1015

UL Style 1015

 PVC Insulated Wire (Poly Vinyl Chloride)

0.031" nominal wall thickness

Max. Temperature 105oC, Max.Voltage 600 Volts

USE:  Internal wiring of Class 1 circuits in electronic equipment.

Download our data sheet



Wire Type

Dimensional Data

RDS Number

Gauge

Stranding

Insulation O.D.

Nominal Weight

UL 1015

(AWG)



(Nominal)

(lbs./1000’)







STANDARD

STRANDING







1015-24-7 -*

24

7/32

.086

4.0

1015-24-19-*

24

19/36

.086

4.1

1015-22-7 -*

22

7/30

.092

5.2

1015-22-19 -*

22

19/34

.092

5.3

1015-20-10 -*

20

10/30

.099

8.5

1015-18-01 -*

18

SOLID

.102

10.1

1015-18-16 -*

18

16/30

.105

10.5

1015-16-26-*

16

26/30

.123

14.0

1015-14-41-*

14

41/30

.139

20.0

1015-12-65-*

12

65/30

.160

28.0

1015-10-105-*

10

105/30

.194

42.0

 *  =  Colors  0 = Black, 1 = Brown, 2 = Red, 3 = Orange, 4 = Yellow, 5 = Green, 6 = Blue, 7 = Violet, 8 = Grey, 9 = White

18 AWG SOLID [1015-18-01-*]  Stocked as bare copper conductor.  Tinned copper conductor available upon request.
